Notes:

• WRAS Approved

• Designed to BS EN 593

• Pressure rating: PN16

• Working Medium: Water

• Temperature range:  0°C to 100°C (nominal pressure rating varies at different temperatures within the range)

• Face to Face: BS EN 558-1 basic series 20

• Flanged to BS4504 / BS EN1092-2

• Top flange confirms to ISO 5211

• Alternative Disc material avaible on request

• Electric / Pneumatic actuators available
